ALPHA 10 - 12

Code: ROB01

Brand: ROBBI

Max. grinding lenght	mm.	950	1200
Max. grinding width	mm.	320	360
Max surface milling width	mm.	315	350
Working surface of table	mm.	900×250	1200×300
Max. long. table table travel	mm.	1120	1380
Automatic table feed per minute	mm.	0÷3000	0÷5000
Distance centre of spindle to column guides	mm.	290	310
Min. height table to grinding wheel	mm.	180	130
Max. height table to grinding wheel	mm.	550	750
Vertical wheel head feed	mm.	320	620
Diameter of segmented grinding wheel	mm.	330	370
Diameter of milling cutter	mm.	320	350
Wheel speed rotation	r.p.m.	700 – 1400	700 – 1400
Cutter speed rotation	r.p.m.	180 – 360	180 – 360
Main spindle rotation motor 50 Hz:	Cv.	5 / 1	5 / 1
Main spindle rotation motor 60 Hz:	Cv.	6 / 1.2	6 / 1
Spindle motor	Cv.	1.3 / 0.8	1.3 / 0.8
Hydraulic pump motor	Cv.	0.5	1
Coolingpump motor	Cv.	0.12	0.12
Dimensions	mm	2250 x 1000	3000 x 1370
Workspace required	mm	3370 x 1000	4380 x 1370
Dimensions of shipping box	m	2.1×1.2×2.1	2.3×1.5×2.33
Approx. net weight	Kg	1150	1700
Shipping weight approx.	kg	1350	1950
